Electric Explosion Proof Stacker
ITEMS | UNIT | CDDB10 | CDDB14 | CDDB10 | CDDB14 | |
Manoeuvre Form | — | Tramptye Type | Front Standing Steer Type | |||
Rated Lifting Capacity | kg | 1000 | 1400 | 1000 | 1400 | |
Load Centre | mm | 500 | ||||
Max. Lifting Height | mm | 3000 | ||||
Mast Tilt Angle (Forward/Backward) | ° | 2/4 | ||||
Lifting Speed ( Full Load ) | mm /s | 160 | ||||
Max. Traveling Speed ( Full Load ) | km/h | 5.8 | ||||
Overall Dimensions | Length | | 2332 | 2495 | ||
Width | 1162 | |||||
Mast Height | 1985 | |||||
Min. Turning Radius | 1690 | 1765 | ||||
Tread | Front Wheels | 1062 | ||||
Rear Wheels | — | |||||
Self Weight | kg | 2050 | 2100 | |||
Acquisition of Certification | - | Type test certification, Explosion-proof certification | ||||
Explosion-proof Marking | - | ExsdeⅡBT4 Gb | ||||
Suitable Explosion-Proof Area | - | 1 Zone, 2 Zone | ||||
Explosive Gas Group | - | IIB | ||||
Temperature Level | - | 135˚C (T4) | ||||
Explosion Proof Certification Organization | - | National Centre for Supervision and Inspection of Explosion-proof Electrical Product Quality (Nanyang, | ||||
Explosion-proof marking: Ex d e mb ib s llB T4 Gb/Ex tD mbD ibD A21 IP65 T135℃.
Suitable for explosive gas environment (1, 2 zone) and non-conductive dust environment (21, 22) use, such as: coal chemical industry, oil chemical industry, military industry, explosives, medicine, papermaking, food processing, wood processing, cement, and other hazardous workplaces.
