Rated lifting capacity

kg

—

1000

1600

Length

mm

L

3087

Width

W

1200

Height

Mast without lifting

B

2120

Heihgt at overhead  guard

H

2160

Max.lifting height

C

3000（Accepts special orders for gantry height）

Fork length

G

920

Min. Underclearance

—

75

Min. turning radias

R

1700

Load centre

—

500

Fork Overhang

K

435

Wheel Base

J

1255

Tread

Front wheels

N

996

Rear wheels

M

0

Mast Tilt angle forward/backward

°

D-E

2/4

Max.lifting speed(Full load)

mm/s

—

250

Max.travel speed(Full load)

km/h

—

11

Battery

Voltage

V

—

80

Capacity

Ah

—

300

Motors Rated Output

walking

kw

—

7.5

lifting

—

6.5

Protection grade

—

—

IP65

tyres

 front tyres

—

—

6.50-10

 rear tyres

—

—

18×7-8

Gradeablity (Full load)

％

—

15

Self Weight

kg

—

3550

3650
